PRELIMINARY
Main Burner Ports
Simmer Flame
Simmer Ring
Burner Cap
High to Low
Flame
Simmer Flame
Burner Adjustment
There is no air shutter adjustment, etc. on this
burner. The only adjustment available is to clean
the burners and clean or replace orifices.
6. CHECK THE FLAME QUALITY
Check for proper burner flame characteristics.
Burner flames should be blue and stable. Some
yellow tipping may be normal on LP Gas. The
flame should not have excessive noise or lift-
ing of the flame from the burner.
Due to differences in gas characteristics and
burner usage (i.e. gas pressure, cleanliness, etc.),
burners may perform differently.
Burner Operation
Two flames are used on all five burners. These
dual flame burners have an upper ring of main
burner ports, which produce the main flame for
high heat cooking from the “HI” knob setting
to the “LO” knob setting.
The bottom simmer flame is used for simmer
heat cooking operations such as melting
chocolate, holding food at serving temperature
and simmering. Both flames are lit when the
knob is between “HI” and “LO”. Only the simmer
flame is lit when the knob is in the “SIM” posi-
tion.
