PRELIMINARY
7. Pull the burner knobs off the control shafts.
8. Remove the two screws from each of the
bezels and remove the bezels.
9. Lift the cooktop off the lower box and re-
move it.
Burner Knob
Bezel
Screws
Remove Cooktop
6. Lift the burner bases off the cooktop and
disconnect the wires from the electrode ter-
minals. Push each of the wires into the lower
box after you disconnect them.
Electrode
Electrode
Wire
Push Wire Into
Lower Box
To Next Page
