CONFIGURATION Menu
Settings Lock
Set to Locked, this icon is displayed and the following settings cannot be changed:
• Mapper
• Sync Mode setting for all inputs
• Output Level
• Dual AES 1+2
• Dual AES 3+4
•
Channel Swap
• Balance
• USB Class
• RS232 Mode
• Factory Reset is disabled
Set to Unlocked if you need to change these settings.
Save Configuration
Once the unit is set up the way you want it, select Save to store the settings in memory.
If you deliberately change the setup later and want to keep it, select Save again to store
the changes.
Restore Configuration
If the unit settings are accidentally changed, select Restore to reload the settings you
saved earlier.
Reset Input Names
If the inputs have been renamed from a computer, this page resets them to the original
names: AES1, AES2, etc.
Factory Reset
This page resets the unit to standard settings. These are:
• Volume to –30dB.
• Balance to centre.
• Input to AES1.
• Mapper to Map 1.
• Sync to Audio for all inputs, except
• USB sync to Master
• SDIF-2 sync to Word Clock In1
• Filter to 1 for all sample rates.
• Dual AES1+2 & 3+4 to Auto.
•
Phase to Normal.
• Output Level to 2V.
• Display to On.
• Brightness to maximum.
• RS232 Mode to Binary.
• Channel Swap to Normal.
• Buffer to On.
• EasyPlay to On.
