dCS Vivaldi DAC User Manual Software Issue 2.0x
November 2016
Vivaldi DAC Manual v2_0x Page 37 English version
Balanced outputs
1 stereo pair on 2x 3-pin male XLR connectors (pin 2 = hot, pin 3 = cold).
These outputs are electronically balanced and floating, the signal balance
ratio at 1kHz is better than 40dB. Output impedance is 3Ω, maximum load is
600Ω (a 10kΩ - 100kΩ load is recommended).
Unbalanced outputs
1 stereo pair on 2x RCA Phono connectors. Output impedance is 52Ω,
maximum load is 600Ω (a 10kΩ - 100kΩ load is recommended).
Size and weight
444mm (17.5”) long x 435mm (17.2”) deep x 151mm (6.0”) high. Allow extra
depth for cable connectors. Allow space for air flow around the unit.
16.2kg (35.65lbs).
Power requirements
Internally set to either 100, 115/120, 220 or 230/240V AC, 50/60Hz.
Power consumption: 23W typical, 50W maximum.
Consumes less than 0.5W when powered down from the front panel.
These specifications are subject to change without notice.
