7.5 Cup and jug sizes
Cup and jug dimensions Edge (small model)
Cups (A)
Maximum cup height (*) 100 mm
Maximum cup diameter 85 mm
Jugs (B)
Maximum jug height 180 mm
Maximum jug diameter 135 mm
(*) The height of the cup stand is fixed and depends on specifications during
ordering.
107
Edge XNA Small Cabinet 18-000 CoEx XL® brewer User Manual 5DUXNQ20M EN V2.1
