3.2.3 Number selection submenu
The Number selection submenu is displayed when the [Number
Selection] button is tapped on the Main menu (see
Main menu -
Cup dispensing on page 21).
Number selection menu (Edge)
1. Currently entered number selection
2. Actual beverage name
3. Beverage price in payment mode — optional
2. Credit in payment mode — optional
5. Numeric keypad with [0...9] buttons
6. Message area
7. [Start] button
8.[Cancel] button
The display shows the following information:
• The unique number entered for the selected beverage is
visible in the small window.
29
Edge XNA Small Cabinet 18-000 CoEx XL® brewer User Manual 5DUXNQ20M EN V2.1
