Procedure
4.2.1.2 Cup dispensing by number — optional
Each beverage with specific strength and/or added ingredients
has its own code. Instead of entering all selections, this code can
be used to dispense the beverage more quickly with required
strength and additional ingredients.
NOTE
This procedure is optional and only available if the [Number
Selection] button is available on the Main menu.
Perform the following steps:
1.
Tap the unique [number] of the desired beverage on the
keypad displayed on the screen.
NOTE
The actual number that needs to be entered here is
shown on the Dispense menu (see
Dispense submenu
on page 31) screen when the beverage is prepared /
during dispense.
2.
Tap the [Start] button to prepare the beverage.
▪ or tap [Cancel] to return to the Main menu (see on page
21).
▪ when payment mode is activated, full payment is needed
first to enable the [Start] button. Check the payment (on
page 44) section for more details.
3.
The Dispense submenu (see on page 31) is now shown and
the beverage is prepared.
▪ tap the [Stop] button to interrupt and stop the dispense.
4. When the dispense is finished the Ready submenu (on page
33) is shown.
▪ do not remove your cup before the message 'Ready, take
your cup (see Message: Ready, take your cup on page 103)'
is visible. The message will remain visible on the screen
until the cup is removed.
▪ To add an additional beverage to the same cup, do not
remove the cup but tap the [Cancel] button and select the
next beverage.
5. The prepared drink is ready.
WARNING
Hot liquid can leak from the outlet nozzle after the
dispense is finished.
41
Edge XNA Small Cabinet 18-000 CoEx XL® brewer User Manual 5DUXNQ20M EN V2.1
