2. To clean the Schaerer grinder, lift and remove the grinder
from the grinder base.
CAUTION
The grinder is filled with beans and ground coffee.
When the grinder house is turned upside down, coffee
beans and ground coffee can fall out.
3. Keep the grinder upside down. Turn the squared top inside
the geared wheel at the top side, or the shaft at the bottom
side, back and forth repeatedly to loosen and remove the
foreign objects.
NOTE
The shaft should rotate easily if nothing is blocking
the grinder.
4. Place the grinder back into the grinder base and continue
with step 12.
TIP
If needed, rotate the squared top a little to allow the
ribbed shaft to fit the grinder motor and is fully
lowered inside the grinder base.
Edge XNA Small Cabinet 18-000 CoEx XL® brewer User Manual 5DUXNQ20M EN V2.1
76
