37
Monitor
Monitor Type LCD Monitor
Screen Size 7" monitor
Wireless Frequency 2400Mhz~2483.5Mhz
Channel Frequencies
4Mhz channel
separation
Number of Cameras
Supported
4
Output Terminal N/A
Resolution 800 RGB (H) x 480 (V)
Speaker Yes
Maximum SD Card Size 128GB
Compression MPEG-4
File Type ASF
Operation Mode FHSS hopping
Scheduled Recording Yes
Automatic Overwrite when
Full
On/Off selected.
Motion Activated Alert Yes
Post Motion Recording Yes
Audio Activated Recording No
Digital Zoom Yes (x2)
Auto-Scanning
Auto sequence
channel, the transition
interval is 6 seconds
Button Lock N/A
Remote Control No
New Video Footage Notifier Yes
Viewing Modes
Single view, 2-CH view,
Quad view
Recording Mode
Manual recording,
Motion recording,
Schedule recording
Battery Operable No
Adjustable Brightness Yes
Video Output No
Operating Temperature 14°F-104°F (-10°C-40°C)
Operating Humidity 0% ~ 85%
Housing Material No
Housing Color black
Monitor Power Input DC 5V 2A
Power Adapter Input AC 100~240V 50/60Hz
Dimensions 180*142*70mm
Weight 444g
SPECIFICATIONS
Camera
Image sensor
1/4" Color CMOS Image
Sensor
IP Rating IP54
Maximum Wireless
Range (Line of Sight)
450 ft
Optimum Wireless Range
(Line of Sight)
150 ft
Wireless Frequency 2400Mhz~2483.5Mhz
Wireless Channel
Frequencies
Hopping Frequencies
Resolution 640 x 480
Night Vision Yes
Number of IR LEDs and
Range
16 LEDS 32Ft
IR LED control Auto
IR Cut Filter Included
Min. Illumination 0 Lux (when IR LEDs on)
Battery Operable No
Viewing Angle 64° (Field Of View)
Focal Length 3.6mm
Focus Type Fixed Focus
Optimal Focal Distance N/A
Microphone Yes
Motion Detection Yes
Housing Material Aluminum & ABS
Housing Color Black
Electronic shutter speed 1/60s~1/100,000s
Signal/Noise Ratio 50dB
Power LED Indicator No
Camera Bracket Yes
Operating Temperature 14°F - 04°F (-10°C - 40°C)
Operating Humidity 0% ~ 85%
Mounting Hardware Included
Camera Power Input 9V DC 600mA
Power Adapter Input 100-240V ~ 50/60Hz
Dimensions 140*55*57mm
Weight 284g
