1. Introduction
1.1 About the Operator's manual
1.1.1 General purpose
This is the Operator’s manual for DEIF’s Compact Genset Controller, the CGC 200 series. The general pur-
pose is to give the operator important information to be used in the daily operation of the unit.
Please read this manual before working with the CGC 200 controller and the genset to be con-
trolled. Failure to do this could result in damage to the equipment or human injury.
The document includes information about push-buttons, LEDs, display readings and an icon list. Basic tasks
are described, as well as using the utility software to monitor operation.
1.1.2 Intended users
This Operator’s manual is mainly intended for the daily user. Using the information in this document, the oper-
ator will be able to carry out simple day-to-day tasks. The operator will also be able to monitor the system
using the utility software.
1.1.3 Revision information
The letter at the end of the document number on the front page indicates the revision number of this docu-
ment.
The latest version of this document can be downloaded at www.deif.com. If you click on the revision letter to
the right of the document name, the revision history is displayed.
1.1.4 Software version
This document is based on the following software versions:
Software type Software version
CGC 200 firmware CGC 200 SW version 1.xx
Utility software Multi-line 2 Utility Software v.3.x.
1.1.5 Other technical documentation
The CGC 200 documentation consists of the following documents:
● Quick start guide
● Front panel
● Initial start-up
● Parameter setting
● Wiring diagram
● Mounting
● Some technical specifications
● Data sheet
● Description, features, functions and approvals
● Layout and dimensions
● Terminals and wiring diagram
● Technical specifications
CGC 200 Operator's manual 4189340770
UK
Introduction
DEIF A/S Page 4 of 43
