Product speciļ¬cation and feature
2-10
Service Manual
2.2 System Overview
This chapter describes the functions and operating principal of the main component.
2.2.1 Front View
This illustration may differ from your machine depending on its model.
1 Document feeder cover 7 Handle 13 Toner cartridge
2 Document feeder width guides 8 Tray 1 14 Manual tray paper width
guides
3 Document feeder input tray 9 Manual tray
4 Document feeder output tray 10 Front door 15 Scanner lid
5 Output support 11 Document output tray 16 Scanner glass
6 Front door handle 12 Control panel
