Dell 1135N - Pick up Roller; Cassette Holder Pad

Dis ssem ly d e ssem ly
3-3
Service Manual
3.15 Cassette holder pad
1. Take out the assette unit. 2. Take off the holder pad by unhooking both
latches.
3.14 Pick up roller
1. Take out the assette unit.
2. arefully turn the printer over.
3. Take off the pick up roller after removing 1 screw.
