Dell 1135N - Fuser Unit Replacement

Dis ssem ly d e ssem ly
3-12
Service Manual
3.6 Fuser Unit
3.6.1 Whole Fuser Unit
1. emove the rear and left cover.
2. emove 4 screws.
3. Unplug the 2 connectors from SMPS board and Main board.
4. Take off the user unit.
