Dell 1135N - Cover; Front Cover; Rear Cover

Dis ssem ly d e ssem ly
3-4
Service Manual
3.3 Cover
3.3.1 Front Cover
3.3.2 Rear Cover
1. Take off the cassette. 2. Take off the front cover by removing both hooks.
1. emove screws on back side of printer.
2. emove the rear cover.
