Dell 1135N - Page 61

Dis ssem ly d e ssem ly
3-1
Service Manual
3.6.3.4 Lamp HalogenG
1. Pull out the harness (Harness- user oint, Harness- user ) which is connected at user Lamp
Halogen. nd loose the two screws ( Left side, ight side each one ) in the red circle.
2. elease the Lamp Halogen.
