Alignment and Troubleshooting
4-13
Service Manual
■ Tech mode Menu Map
Depth1 Depth2 Depth3 Depth4 Common
Data Setup Send Level -9~-15 -12 4-in-1
DTMF Level [Hi]=xx, [Lo]=xx 4-in-1
Pause Time 0~9 4-in-1
Dial Mode Tone,Pulse Tone 4-in-1
Modem Speed 33.6, 28.8, 14.4, 12.0, 9.6, 4.8 33.6 4-in-1
Error Rate 5%, 10% 10% 4-in-1
Clear All Mem. Common
Toner Low Level [1-30]% : 10 Common
Clear Count Total Page Count Enter Password Common
Common
4-in-1
Engine Footer Off* Common
On Common
Width Sensor On* Common
Off Common
Machine Test Switch Test REDUCE_PANEL Common
COMPLETE_PANEL Common
Modem Test 4-in-1
Dram Test Common
Rom Test Common
Shading Test Adjust Shading ? Shading&Print Common
Restart Machine Common
Report All Report Common
Configuration Common
Supplies Info Common
Error Info Common
Protocol Dump 4-in-1
Usage Page Common
ComponentCheck Common
Service Support Common
