Alignment and Troubleshooting
4-20
Service Manual
■ EDC Mode Menu
0. Cover Status
Item Description
Front Cover When the front cover opened, “Open” message display LCD. If the front
cover closed, “Closed” message display LCD.
1. Sensor Status
Item Description
Regi/Feed/Exit Sensor Manually open and close the actuator of the sensor [Regi, Feed, and/or
Exit Sensor] you wish to check, the message “Without Paper” and “With
Paper” message will be displayed.
Empty Manually open and close the actuator of the Empty Sensor, the message
“Present” and “Empty” message will be displayed.
2. Motor Test
Item Description
Main Mtr Nor. If “OK” key is pushed after “ON” displayed, motor will be run. Main motor
will auto - stop after 60 seconds and ”OFF” message will be displayed.
Slow If “OK” key is pushed after “ON” displayed, motor will be slowly run.
Main motor will auto - stop after 60 seconds and ”OFF” message will be
displayed.
3. Fan Test
Item Description
Fuser Fan If “OK” key is pushed after “ON” displayed, fan will be run. Fuser fan will
auto - stop after 10 seconds and ”OFF” message will be displayed.
4. Clutch Test
Item Description
Pick up Clutch When “OK” key is pushed after ”ON” message displayed, clutch turns on.
Pick up Clutch will be turn off after 3 seconds and ”OFF” message will be
displayed.
Regi Clutch When “OK” key is pushed after ”ON” message displayed, clutch turns on.
Regi Clutch will be turn off after 3 seconds and ”OFF” message will be
displayed.
