26 Installation
www.dell.com | support.dell.com
To install a SIP in a 1U or 2U cable management arm:
Route the SIP through the cable management arm. The following series of figures demonstrate the
correct configuration for your cable management arm.
Figure 2-10. 1U Cable Arm - Side View
Figure 2-11. 2U Cable Arm - Side View
Figure 2-12. 1U or 2U Cable Arm - Top View
Figure 2-13. Cable Management Arm - Side View
