Dell 2161DS - Broadcasting to Servers

Analog Port Operation 55
Figure 3-36. Command Dialog Box
3 Select Scan Enable in the Command dialog box.
To cancel scan mode:
1 Select a server if OSCAR is open.
-or-
Move the mouse or press any key on the keyboard if OSCAR is not open. Scanning will stop at
the currently selected server.
-or-
Press <Print Screen>. The
Main dialog box will appear.
2 Click Commands . The Command dialog box appears.
3 Clear Scan Enable .
Broadcasting to Servers
The analog user can simultaneously control more than one server in a system, ensuring that all
selected servers receive identical input. You can choose to broadcast keystrokes and/or mouse
movements independently.
NOTE: You can broadcast to only one server per ARI connection.
To access the Broadcast dialog box:
1 Press <Print Screen>. The Main dialog box will appear.
2 Click Setup - Broadcast . The Broadcast dialog box appears.
