Dell 2161DS - Controlling the Status Flag

Analog Port Operation 39
Controlling the Status Flag
The status flag displays on your desktop and shows the name or EID number of the selected server
or the status of a port. Use the
Flag dialog box to configure the flag to display by server name or
EID number, or to change the flag color, opacity, display time, and location on the desktop.
To access the
Flag dialog box:
1 Press <Print Screen>. The Main dialog box will appear.
2 Click Setup - Flag . The Flag dialog box appears.
Table 3-3. OSCAR Status Flags
Flag Description
Flag type by name
Flag type by EID number
Flag indicating that the user has been
disconnected from all systems
Flag indicating that Broadcast mode is
enabled
