42 Analog Port Operation
www.dell.com | support.dell.com
To password protect your console:
1
Set your password as described in the previous procedure.
2
Select
Enable Screen Saver.
3
Type the number of minutes for Inactivity Time (from 1 to 99) to delay activation of password
protection and the screen saver feature.
4
For Mode, select
Energy
if your monitor is ENERGY STAR™ compliant; otherwise select
Screen
.
CAUTION: Monitor damage can result from the use of Energy mode with monitors not compliant with
ENERGY STAR™.
5
(Optional) Click
Test
to activate the screen saver test which lasts 10 seconds then returns you
to the
Security
dialog box.
6
Click
OK
.
To log in to your console:
1
P
re
ss <P
rint S
creen
> to launc
h OSCAR. The
Password
dialog box appears.
2
Type your password and then click
OK
.
3
The
Main
dialog box appears if the password was entered properly.
To automatically log out of a server when inactive:
1
In the
Main
dialog box, click
Setup - Security.
If you have password protection, the
Password
dialog box appears.
2
Type your password, and then click
OK
. The
Security
dialog box appears.
3
In the
Inactivity Time
text box, enter the length of time you want to stay connected to a
server before it automatically disengages you.
4
Click
OK
.
To remove password protection from your console:
1
In the
Main
dialog box, click
Setup - Security
. the
Password
dialog box appears.
2
Type your password, and then click
OK
.
3
In the
Security
dialog box, single-click and press <Enter> or double-click in the
New
box.
Leave the box blank. Press <Enter>.
4
Single-click and press <Enter> or double-click in the
Repeat
box. Leave the box blank. Press
<Enter>.
5
Click
OK
if you only want to eliminate your password.
To enable the screen saver mode with no password protection:
