Dell Alienware m17 R3 - Page 52

About this task
NOTE: The heat sink may become hot during normal operation. Allow sufficient time for the heat sink to cool before you
touch it.
CAUTION: For maximum cooling of the processor, do not touch the heat transfer areas on the heat sink. The oils in your
skin can reduce the heat transfer capability of the thermal grease.
The following image indicates the location of the fan and heat-sink assembly and provides a visual representation of the removal
procedure.
52
