Next steps
1. Install the
keyboard.
2. Install the
power-button assembly.
3. Install the power-adapter port.
4. Install the touchpad.
5. Follow step 3 to step 22 in installing the system board.
6. Install the right I/O-board.
7. Install the
keyboard-controller board.
8. Install the display assembly.
9. Install the battery.
10.Install the rear I/O-cover.
11. Install the
speakers.
12. Install the 2280 solid-state drive in M.2 slot two, if installed.
13. Install the 2230 solid-state drive in M.2 slot two, if installed.
14. Install the 2280 solid-state drive in M.2 slot one, if installed.
15.Install the 2230 solid-state drive in M.2 slot one, if installed.
16.Install the
base cover.
17. Follow the procedure in After working inside your computer.
64
