Dell D13M - 2 Removing and Installing Components; Recommended Tools; Removing the Cover; Installing the Cover

a Lift the retention tabs [1] to release the front bezel [2].
b Lift the front bezel to remove it from the computer [3].
Installing the front bezel
1 Hold the bezel and ensure that the hooks on the bezel snap into the notches on the computer.
2 Rotate the front bezel toward the computer.
3 Press the front bezel until the tabs click into place.
4 Install the cover.
5 Follow the procedure in After Working Inside Your Computer.
Removing the hard drive assembly
1 Follow the procedure in Before Working Inside Your Computer.
2 Remove the cover.
3 Disconnect the data cable and the power cable from the hard drive [1].
4 Press the blue securing bracket tabs [2] and lift the hard drive bracket out of the hard drive bay [3].
5 Flex the hard drive bracket and remove the hard drive from the hard drive bracket.
8
Removing and installing components
