Figure 37. Removing an intrusion switch
Next step
Installing intrusion switch.
Installing intrusion switch
Prerequisite
Follow the safety guidelines listed in Safety instructions.
Steps
1 Align the intrusion switch with the intrusion switch slot.
Figure 38. Installing intrusion switch
2 Slide the intrusion switch until it is rmly seated in the intrusion switch slot.
3 Connect the intrusion switch cable to the connector on the system board.
Next steps
1 Install internal PERC riser.
2 Install air shroud.
52
Installing and removing system components
