10 | The E1200 System
www.dell.com | support.dell.com
Figure 2-1. E1200i AC Chassis Front View
RPM 1
Line Card Slots
Air Filter
Line Card Slots
AC Power Supply
AC Power Plug
Air Vents
Switch Fabric
Cable Management System
Module (SFM)
Blank (BLNK)
