System Specifications | 79
D
System Specifications
This appendix contains two major sections:
• E1200i AC Chassis Physical Design
• E1200i AC System Power Requirements
• E1200i DC Chassis Physical Design
• E1200i DC System Power Requirements
• Environmental Specifications
• Agency Compliance
E1200i AC Chassis Physical Design
Parameter Specifications
Height 42 inches (106.68 cm)
Width 17.40 inches (44.20 cm)
Depth (without cable management system) 22.25 inches (56.51 cm)
Chassis weight with factory-installed components
(backplane and air filter)
139 pounds (approx.) (63.05kg)
Weight fully loaded (backplane, air filter, 2 fan trays, 10
SFMs, RPMs, and 14 line cards)
394 pounds (approx.) (178.7 kg)
Mounting Attached rack mount brackets are factory set for front
mounting in a standard 19-inch rack.
Mounting brackets are adjustable for center and rear
mounting.
Optional brackets are available for front or center
mounting in a 23-inch rack or cabinet.
Rack clearance required Front: 18 inches
Rear: 20 inches
Thermal Output
Maximum for fully loaded chassis 7,784W (26,578BTU/HR)
Minimum for chassis with one 48-port 1GE line card 1,450W (4,951 BTU/HR)
