12 | The E1200 System
www.dell.com | support.dell.com
Figure 2-3. E1200i DC Chassis Front View
RPM 1
Line Card Slots
Air Filter
Line Card Slots
DC Power Supply
Air Vents
Switch Fabric
Cable Management System
DC Power Supply
Module (SFM)
Blank (BLNK)
