Removing the display hinges
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the rear cover.
4 Remove the wireless card.
5 Follow the procedure from step 1 to step 17 in Removing the computer base.
6 Remove the display assembly.
7 Remove the display bezel.
Procedure
1 Peel the tape that secures the display hinge to the display back-cover.
2 Remove the eight screws (M2.5x2.5) that secure the display hinges to the display back-cover.
3 Lift the display hinges o the display back-cover.
45
80 Removing the display hinges
