Removing the display panel
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Topics:
• Prerequisites
• Procedure
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the rear cover.
4 Remove the wireless card.
5 Follow the procedure from step 1 to step 17 in Removing the computer base.
6 Remove the display assembly.
7 Remove the display bezel.
Procedure
1 Remove the four screws (M2x2.5) that secure the display panel to the display back-cover.
2 Gently lift the display panel and turn it over.
3 Peel o the tape that secures the display cable to the display panel.
4 Open the latch and disconnect the display cable from the display panel.
5 Lift the display panel away from the display back-cover.
47
84 Removing the display panel
