Dell Latitude 7400 - Installing the Touchpad Button Board

Installing the touchpad button board
1. Place the touchpad button board on the palmrest assembly [1].
2. Replace the two (M2x2.5) screws to secure it to the palmrest assembly [2].
3. Connect the touch pad button board cable to the touchpad module [3].
