Dell Latitude 7400 - Installing the Display Panel

Installing the display panel
1. Connect the EDP cable to the connector on the display panel [1] and close the actuator to secure the connector [2].
2. Adhere the adhesive tape over the EDP connector on the display panel [3] and flip over the display panel on the back cover
[4].
64
Removing and installing components
