Installing the smart card reader
1. Replace the smart card reader into its slot on the palmrest assembly [1].
2. Replace the four (M2x2.5) screws securing it to the palmrest assembly [2].
3. Connect the touchpad button board cable to the touchpad module [3].
4. Connect the smart card reader cable to the USH board [4].
