Dell Latitude E6330 - Installing the Keyboard

9. Disconnect the keyboard cable from the keyboard.
10. Remove the keyboard cable from the keyboard.
Installing the Keyboard
1. Connect the keyboard cable and secure it to the keyboard using the tape.
2. Connect the keyboard cable to the system board.
3. Slide the keyboard into its compartment and ensure that it clicks into place.
4. Tighten the screws to secure the keyboard on the palmrest.
5. Flip the computer and tighten the screws to secure the keyboard.
6. Install the keyboard trim.
7. Install the battery.
8. Follow the procedures in After Working Inside Your Computer .
