Dell Latitude E6330 - Removing the Wireless Local Area Network (WLAN) Card; Installing the WLAN Card; Removing the Bluetooth Module

Removing the Wireless Local Area Network (WLAN) Card
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery.
3. Remove the base cover.
4. Disconnect the antenna cables from the WLAN card and remove the screw that secures the WLAN card to the
computer. Remove the WLAN card from the computer.
Installing the WLAN Card
1. Insert the WLAN card into its connector at a 45–degree angle into its slot.
2. Connect the antenna cables to their respective connectors marked on the WLAN card.
3. Tighten the screw to secure the WLAN card to the computer.
4. Install:
a) base cover
b) battery
5. Follow the procedures in After Working Inside Your Computer .
Removing the Bluetooth Module
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery.
3. Remove the base cover.
4. Disconnect the bluetooth cable from the system board.
5. Remove the bluetooth cable from its routing on the computer.
