Dell Latitude E6330 - Removing the LED Board

Removing the LED Board
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a) battery
b) display bezel
c) display panel
3. Remove the screw that secures the LED board to the display assembly.
4.
Remove the LED-board support plate from the display assembly.
5. Disconnect the LED-board cable from the LED board.
6. Remove the screw that secures the LED board to the LED-board support plate.
47
