56 Drives
Drive Interface Connectors
The drive cable connectors are keyed for correct insertion. Properly align the
cable connector key on the cable and the drive before connecting.
Connecting and Disconnecting Drive Cables
When connecting and disconnecting a SATA data cable, disconnect the cable
using the pull-tab.
1 power cable 2 data connector
1 interface cable 2 interface connector
