Installing the WLAN card
1. Insert the WLAN card into the connector at a 45–degree angle.
2. Close the plastic cover over the WLAN card.
3. Tighten the screw to secure the WLAN card to the computer.
4. Connect the antenna cables to the connectors marked on the WLAN card.
5. Install the:
a. battery
b. back cover
6. Follow the procedure in After working inside your computer
Removing the touchpad
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. back cover
b. battery
c. WLAN card
3. To release the touchpad:
a. Peel away the adhesive tape [1].
b. Disconnect the connector cables from the system board as indicated [2] [3] [4. ]
Removing and installing components
21
