Installing the LED board
1. Place the LED module into its slot on the computer chassis.
2. Tighten the screw to secure the LED module to the computer chassis.
3. Connect the LED module cables to the computer chassis.
4. Install the:
a. battery
b. back cover
5. Follow the procedure in After working inside your computer
Removing the speakers
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. back cover
b. battery
3. To remove the speaker cables:
a. Disconnect the speaker connector cables from the system board and the LED board. [1] [2].
b. Unroute the speaker cable from around the LED board [3].
Removing and installing components
29
