Installing the display
1. Connect the display connector cable to its connector on the display panel.
2. Affix the adhesive tape over the connector.
3. Flip the display around and align it along the edges of the display panel.
4. Install the screws that secure the display to the display panel.
5. Install the:
a. display hinges
b. display bezel
c. display assembly
d. system fan
e. LED board
f. WLAN card
g. battery
h. back cover
6. Follow the procedure in After working inside your computer
Removing the palmrest
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. back cover
b. battery
c. WLAN card
d. LED board
e. system fan
f. display assembly
Removing and installing components
41
