b. battery
c. LED board
d. WLAN card
e. system fan
f. display assembly
3. To remove the display bezel:
a. Lift the corners of the bezel with a plastic scribe to remove it .
Installing the display bezel
1. Place the display bezel on the display panel and press along the edges until it clicks in place.
2. Install the:
a. display assembly
b. WLAN card
c. system fan
d. LED board
e. battery
f. back cover
3. Follow the procedure in After working inside your computer
Removing the display panel hinges
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. back cover
b. battery
c. WLAN card
d. LED board
Removing and installing components
37
