Removing the camera
WARNING
: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in
Before working inside your computer. After working inside your computer, follow the instructions in After working inside
y
our computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/
r
egulatory_compliance.
Prerequisites
1 Remove the base cover
.
2 Remove the wireless card.
3 Remove the fan.
4 Remove the heat sink.
5 Remove the display assembly.
6 Follow the procedure from step 1 to step 6 in "Removing the display panel".
Procedure
1 Using a plastic scribe, remove the camera module from the display-panel assembly.
2 Roll over the camera module.
3 Release it from the adhesive tape and disconnect the camera cable from the camera module.
40
Removing the camera 73
