Table 4. S4100-ON Series I/O-side details(continued)
Platform Description
S4148T-ON
● 48 fixed 100M/1G/10GbE copper BaseT RJ45 ports
● Two fixed 40GbE QSFP+ ports
● Four fixed 100GbE QSFP28 ports
● Seven-segment stacking indicator.
● One micro-USB-B console port
● One USB type-A port
S4148U-ON
● 24 Ethernet SFP+ ports or Ethernet-only SFP+ ports
● 24 fixed Ethernet SFP+ optical ports
● Two fixed 40GbE QSFP+ ports
● Four fixed 100GbE QSFP28 ports
● Seven-segment stacking indicator.
● One micro-USB-B console port
● One USB type-A port
Figure 2. S4128F-ON I/O-side view
1.
Twenty-eight SFP+ optical ports 2. Two QSFP28 optical ports
3. Micro USB-B console port 4. USB Type-A
Figure 3. S4148F-ON I/O-side view
1.
Forty-eight SFP+ optical ports 2. Four QSFP28 ports
3. Two QSFP+ optical ports 4. Micro USB-B console port
5. USB Type-A
S4100–ON Series switch 9
