Dell Precision M2800 - Removing the Secure Digital (SD) Card

5. ExpressCard slot 6. optical drive
7. coin-cell battery 8. base-corner cover (left)
9. WWAN card 10. WLAN card
11. docking port 12. battery bay
13. base-corner cover (right)
Figure 2. Top View — Keyboard and Palmrest Assembly removed
1. WiFi-switch board 2. speaker
3. ExpressCard cage 4. system board
5. speaker 6. hard-drive bay
7. VGA board 8. display assembly
Removing the Secure Digital (SD) Card
1. Follow the procedures in Before Working Inside your computer.
2. Press in on the SD card to release it from the computer. Slide the SD card out of the computer.
