Dell Precision M2800 - Installing the Hard Drive; Removing the Optical Drive

Installing the Hard Drive
1. Install the hard-drive isolation on the hard drive.
2. Attach the hard-drive caddy to the hard drive.
3. Tighten the screws to secure the hard-drive caddy to the hard drive.
4. Slide the hard drive into the computer.
5. Tighten the screws to secure the hard drive to the computer.
6. Install the battery.
7. Follow the procedures in After Working Inside Your Computer.
Removing the Optical Drive
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Press the optical-drive latch to release the optical drive and pull the optical drive from the computer.
4. Remove the screw that secures the optical-drive latch to the optical drive. Slide the optical-drive
latch and remove it from the optical-drive.
