Dell Precision M2800 - Removing the Palmrest Assembly

4. Align the keyboard trim on its compartment and press along the sides until it snaps in place.
5. Install the battery.
6. Follow the procedures in After Working Inside Your Computer.
Removing the Palmrest Assembly
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. SD card
b. ExpressCard
c. battery
d. keyboard
e. display-hinge cap
f. base cover
g. base-corner covers
3. Remove the screws that secure the palmrest assembly to the base of the computer.
30
