Dell Precision M2800 - Removing the Display-Hinge Cap; Installing the Display-Hinge Cap

3. Install:
a. system board
b. ExpressCard cage
c. VGA board
d. processor
e. heatsink
f. WWAN card
g. WLAN card
h. memory
i. coin-cell battery
j. power connector
k. palmrest assembly
l. base-corner covers
m. base cover
n. display-hinge cap
o. optical drive
p. hard drive
q. keyboard
r. battery
s. ExpressCard
t. SD card
4. Follow the procedures in After Working Inside Your Computer.
Removing the Display-Hinge Cap
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the screws that secure the display-hinge cap to the computer and remove the display-hinge
cap from the computer.
Installing the Display-Hinge Cap
1. Align the display-hinge cap with the screw holes.
2. Tighten the screws to secure the display-hinge cap to the computer.
3. Install the battery.
