6. Pry the palmrest assembly upwards and remove it from the computer.
Installing the Palmrest Assembly
1. Align the palmrest assembly to its original position in the computer and snap it into place.
2. Tighten the screws to secure the palmrest assembly to the computer.
3. Connect the following cables:
a. power-button
b. touchpad
c. fingerprint-reader
4. Flip the computer and tighten the screws to secure the palmrest assembly to the base of the
computer.
5. Install:
a. base-corner covers
b. base cover
c. display-hinge cap
d. keyboard
e. battery
f. ExpressCard
g. SD card
6. Follow the procedures in After Working Inside Your Computer.
33
