Installing the Speakers
1. Align the speakers in the slot on the palmrest assembly.
2. Route the speaker cable through the routing tabs on the palmrest assembly.
3. Tighten the screw to secure the speakers to the palmrest assembly.
4. Connect the speaker cable to the system board.
5. Install the:
a) battery
b) base cover
6. Follow the procedures in
After Working Inside Your Computer
.
Removing the Wireless Local Area Network (WLAN) Card
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the:
a) base cover
b) battery
3. Perform the following steps to remove the WLAN card:
a) Remove the screw to release the bracket that secures the WLAN card to the computer.
b) Disconnect the antenna cables from the WLAN card.
c) Slide and remove the WLAN card from its connector on the I/O board.
17
