Installing the Coin-Cell Battery
1. Replace the coin-cell battery in its slot in the computer.
2. Connect the coin-cell battery cable to the I/O board.
3. Install the:
a) WLAN card
b) battery
c) base cover
4. Follow the procedures in
After Working Inside Your Computer
.
Removing the mSATA Card
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the:
a) base cover
b) battery
3. Disconnect the I/O-board cable from the system board and I/O board.
19
